PIR Presence Detector with Relay Output Compatible with Magic Tecnel 3700R Series

The Tecnel 3700R is the professional solution for those who want to add automation features to a Magic series system without sacrificing its original aesthetics. Unlike cheaper sensors, the "R" version features an internal relay, meaning it can handle any type of load without the flickering or incompatibility issues typical of models that only control resistive loads.
The sensor monitors the environment through an infrared lens that detects changes in body heat. Once installed, its operation can be customized using two internal trimmers:
0.Timing Adjustment: allows you to set how long the light should remain on (from a few seconds to several minutes).
0. Twilight Control: allows you to decide the level of darkness required for the sensor to activate the light, avoiding unnecessary switching on in the presence of sunlight.
Main Features:
·Universal Load Compatibility: Thanks to the relay contact, it controls LED, neon, halogen and energy-saving lamps.
·1 Module Design: Fits perfectly into the Magic series frames, taking up minimal space.
·High Sensitivity: Wide detection range for effective room coverage.
·Tecnel reliability: Robust component, ideal for intensive use in domestic or professional environments.
Technical Specifications:
FeatureValue
Product Code3700R
BTicino Magic Compatible Series
PIR (Passive Infrared) Sensor Technology
Power supply 230V AC - 50Hz
Output Type: Relay (changeover contact)
Maximum Load 5A (Resistive)
Time AdjustmentFrom 10 seconds to approximately 12 minutes
Lux AdjustmentFrom 5 Lux to 500 Lux (Twilight)
Coverage Angle ∞110°

What can it be used for? (Intended use)
The 3700R detector is extremely versatile and can be used for:
0. Utility Rooms and Storage Rooms: Forget about fumbling for the light switch when your hands are full; the light turns on as soon as you enter and turns off automatically.
0.Corridors and hallways: Ideal for safe passage during the night, activating the lighting only when actually necessary.
0.Bathrooms and Laundry Rooms: Perfect for automating both the lighting and, possibly, the bathroom extractor fan.
0.Home Security: Can be used to activate a buzzer or alarm light when unexpected motion is detected.
0. Energy Savings in Offices: Ensures that lights are never left on unnecessarily in unattended rooms, reducing energy bills.
Technical Tip: For optimal coverage, install the sensor at a height of 1 to 1.5 meters. Avoid placing it directly above heat sources such as radiators or stoves to prevent accidental activation.
