40va 12 / 24v 220va AEG panel electric transformer

The switchboard safety transformer is available with PTC short-circuit protection. Operation is completely trouble-free. The terminals with safety connection are equipped with Pozidriv screws and have an IP20 degree of protection.
Reduction to a very low (safe) level of the voltage used primarily as a control voltage to decrease the risk of electrocution, which can be accentuated by environmental circumstances (e.g. high degree of humidity outdoors, near a swimming pool, etc.). The applications are innumerable, but they are mainly used for ringtones and transformers.
Technical features
- Primary voltage 230-240V
- Secondary voltage 12-24V
- Maximum load rated power
- PTC short circuit protection
- Operating temperature 20 ° to 40 ° C
- Degree of protection IP20
- Insulation voltage 4kV
- Pozidriv clamping screws 1
- Cable clamp from 0.5 to 16mmq
- Din module connection 4
- 40VA output power
