Interruttore magnetotermico 1 modulo 1P+N 25A 4.5 KA
Interruttore magnetotermico 1 modulo 1P+N 25A 4.5 KA

1 module 1P N 25A 4.5 KA circuit breaker", "detectedSourceLanguage": "it

Tecno
EAMT1PNC25K45
€5.60
Tax included
It is suitable for protecting single-phase 230V lines such as: Home or office sockets Small appliances Lighting circuits with high loads Dedicated lines (e.g. washing machine, dishwasher) up to 25A Domestic electrical panels with limited space (only 1 module) ", "detectedSourceLanguage": "it

Description

The Tecnoline EAMT1PNC25K45 miniature circuit breaker is a 1-module, bipolar (1P N), C curve, 25A, breaking capacity 4.5 kA. It is used to protect a domestic electrical circuit from: Overloads (thermal part) Short circuits (magnetic part) In practice: it automatically cuts off the current when the circuit absorbs too much or when there is a short.

Technical Features
- Number of poles 1 N
- Intervention curve C
- Rated voltage (Ur 240v AC
- Rated current (In 25A
- Number of modules 1M
- IP20 protection rating
- Mounting type DIN mount
- Dimensions - 83.8 x 17.8 x 78.2 mm
- Screw terminal type
- Magnetic / thermal operation ", "detectedSourceLanguage": "it
